L. David Roper

http://www.roperld.com/personal/RoperLDavid.htm

2 July, 2016

The U.S. Energy Information Administration gives data for extraction rates and current estimated reserves for crude-ol extraction for the world . The 2011 estimated reserves value for crude oil is 1474 x 10^{9} barrels.

One often reads in the press and/or on the Internet that a certain fossil fuel is sufficiently available to last hundreds of years. That is a meaningless statement because it implies, if not explicitly stated, the assumption that the current rate of extraction will remain the same into the future, which will not be even close to reality.

Any mineral, such as a fossil fuel, follows a depletion curve in its extraction rate in that it rises quickly and then slows down to a peak and they falls rapidly either faster or slower than it rose. That is, the peaked depletion curve may be asymmetric. The area under the depletion curve is the amount that will eventually be extracted, which is the sum of the amount already extracted plus the true extractable reserves. There is an excellent mathematical method to arrive at a depletion curve for any mineral. The basic equation is the Verhulst function:

The sum is due to the fact that the extraction rate may have more than one peak.

For each peak is the amount to be eventually extracted, is the rising exponential time constant in years units, n is the falling exponential time constant and t_{1/2} is the time in years units at which the resource is one-half depleted. The parameter n determines the amount of skewing at large times. For n = 1 the extraction curve is symmetrical and the peak occurs at t_{1/2}. The deviation of the peak time from t_{1/2} is negative for n > 1 (skewed toward large times) and is positive for n < 1 (skewed toward small times).

When a peak is symmetrical, the Verhulst function simplifies to

.

Any study of fossil fuel extraction that claims to predict the future of the extraction, to be honest, must present the predicted depletion curve, not some meaningless statement about the future extraction. Then any study that refutes that prediction must show a depletion curve that disagrees with the one being refuted. The area under the refuting depletion curve must be equal to the sum of the amount already extracted plus a defensible estimate of the reserves. The best current estimate of reserves for fossil fuels is given and regularly updated by the Energy Information Agency (EIA) of the United States Department of Energy. If the area under a depletion curve greatly deviates from the EIA value, a rational explanation must be given why.

Four Verhulst functions do an excellent job of fitting the yearly extraction data for crude oil in the United States:

The red curve is for slightly more than the 2011 EIA reserves estimate (1474x10^{9} barrels). Reserves values are rough estimates, so are not expected to be accurate. The blue curve is for doubling the reserves to ~3000x10^{9} barrels. The truth will probably be somewhere in between the two curves. The green curve is the depletion curve for crude-oil extraction in the U.S. assuming high reserves of 75x10^{9} barrels.

There may be another peak instead of a continuation of the second peak.

World crude-oil reserves estimated by the EIA since 1990 are:

This two symmetric Verhulst-function fits are made so that the peak values are ~1500 x10^{9} barrels and ~3000 x10^{9} barrels, which are used to get the depletion curves above.

When a reserves estimate is rising with time, the eventual peak is the value that should be used in fitting the extraction rate. When a reserves estimate is falling with time, the last-available estimate is the value that should be used in fitting the extraction rate.

The blue curve in the first graph above probably is a maximum representation of the future of crude-oil extraction for the world; the red curve may be more likely. The last peak of the curves could be higher but narrower or lower but wider. Thus, it appears that the extraction of crude-oil for the world will peak before 2050 and then fall rapidly.
